Products Port Machinery Empty Container Handler XCH907E
Empty Container Handler
XCH907E
  • Max. Lifting capacity（kg）
    9000
  • Max. Lifting Height（mm）
    18780
  • Number of Stacking
    7 (8’6”) /6 (9’6”)
Applicable working conditions
  • Logistic
    Logistic
Request a Quote
XCH907E
  • FEATURE
  • Parameter
  • Inquiry
  • recommend
FEATURE
XCMG XCH907E uses Drive Motor: DM250H41.P12H2 motor, with Power: 100KW; Lifting Motor: DM085H37, with power: 70kW. Oil Pump Motor: UM050H31-C, with Power: 120kW. Water-cooled permanent magnet synchronous motor. XCMG spreader for single containers, applicable for handling 20' and 40' containers. Maximum lifting capacity is 9 t, and sideways opening is ±600 mm. Electric proportional variable pump system, with load sensitive function, energy saving. An air-cooled hydraulic oil radiator is used to cool the system. Oil tank capacity: 420 L. Two-stage, telescopic pole, anti-torque design provides better operating performance and anti-torque capability. Cabin Integrated design for driving and operating functions, simple and artistic appearance. Panoramic, low instrument panel design, wide view. Ergonomically designed, spacious, and comfortable interior with high-power heating and air conditioning devices. The large screen display is easy to use.
Parameter
Parameter XCH907E
Payload（kg） 25873
Drive motor power（kW） 100
Max gradeability（%） 30
Max lifting height（mm） 18780
Max. Lifting Capacity（kg） 9000
Number of Stacking 7 (8’6”) /6 (9’6”)
Spreader width（mm） 6080
Max lifting speed（mm/s） 450
