| Item | Unit | Parameters |
|---|---|---|
| Engine model | QSB6.7 | |
| Rated power/speed | kW/rpm | 194/2200 |
| Machine dimension (standard) | mm | 9370 x 2800 x 3522 |
| Machine weight (standard) | kg | 19000 |
| Tire specification | 20.5-25 | |
| Wheel track | mm | 620 |
| Axle distance between front and rear | mm | 2280 |
| Minimum ground clearance, front axle | mm | 6531 |
| Wheel base between middle and rear | mm | 1622 |
| Drive speed, forward | km/h | 5/8/11/19/26/47 |
| Drive speed, reserve | km/h | 5/11/26 |
| Traction force | kN | ≥99 |
| Maximum gradeability | % | ≥25 |
| Tire inflation pressure | kPa | 350 |
| Work system pressure | MPa | 22 |
| Transmission box pressure | MPa | 1.85-2.2 |
| Maximum steering angle, front wheel | o | ±48 |
| Allowable tilt angle, front wheel | o | ±17 |
| Maximum oscillation, front axle | o | ±15 |
| Maximum oscillation, balance box | o | Front 10, rear 10 |
| Maximum steering angle, frame | o | ±20 |
| Minimum turning radius | m | 7.9 |
| Maximum lift above ground | mm | 480 |
| Maximum cutting depth | mm | 715 |
| Maximum tilt angle | o | 90 |
| Cutting angle | o | 29-69 |
| Swivel angle | o | 360 |
| Length x height | mm | 4270 x 610 |
| Coolant | L | 50 |
| Fuel tank | L | 270 |
| Engine | L | 24 |
| Transmission box | L | 38 |
| Balance box | L | 170 |
| Drive axle | L | 44 |
| Hydraulic oil | L | 190 |
