| Item | Unit | Parameters |
|---|---|---|
| Engine model | 6CTA8.3-C215 | |
| Rated power/speed | kW/rpm | 160/2200 |
| Machine dimension (standard) | mm | 8970 x 2625 x 3420 |
| Machine weight (standard) | kg | 16500 |
| Tire specification | 17.5-25 | |
| Wheel track | mm | 2156 |
| Axle distance between front and rear | mm | 6219 |
| Minimum ground clearance, front axle | mm | 430 |
| Wheel base between middle and rear | mm | 1538 |
| Drive speed, forward | km/h | 5/8/11/19/23/38 |
| Drive speed, reserve | km/h | 5/11/23 |
| Traction force | kN | ≥85 |
| Maximum gradeability | % | ≥25 |
| Tire inflation pressure | kPa | 260 |
| Work system pressure | MPa | 18 |
| Transmission box pressure | MPa | 1.4-1.8 |
| Maximum steering angle, front wheel | o | ±48 |
| Allowable tilt angle, front wheel | o | ±17 |
| Maximum oscillation, front axle | o | ±15 |
| Maximum oscillation, balance box | o | ±15 |
| Maximum steering angle, frame | o | ±27 |
| Minimum turning radius | m | 7.3 |
| Maximum lift above ground | mm | 450 |
| Maximum cutting depth | mm | 500 |
| Maximum tilt angle | o | 90 |
| Cutting angle | o | 28-70 |
| Swivel angle | o | 360 |
| Length x height | mm | 3965 x 610 |
| Coolant | L | 50 |
| Fuel tank | L | 280 |
| Engine | L | 24 |
| Transmission box | L | 38 |
| Balance box | L | 120 |
| Drive axle | L | 36 |
| Hydraulic oil | L | 110 |
