| Project | Unit | Parameters |
|---|---|---|
| The working parameters | ||
| Maximum drilling diameter | Mm | 1500 / 1300 |
| Maximum drilling depth | m | 56 |
| Engine parameters | ||
| Model | - | QSB7. |
| Rated power | kW | 150 |
| Powerhead parameters | ||
| Maximum output torque | kN.m | 160 |
| Speed. | r/min | 5-35 |
| Pressurized cylinder parameters | ||
| Maximum pressure | Kn | 160 |
| Maximum lift force | Kn | 160 |
| Maximum travel | m | 4.2 |
| Pressurized roll-up parameters | ||
| Maximum pressure | Kn | 160* |
| Maximum lift force | Kn | 180* |
| Maximum travel | m | 13* |
| The main roll-up parameter | ||
| Maximum lift force | Kn | 160 |
| Maximum roll-up speed | m/min | 80 |
| Sub-roll-up parameters | ||
| Maximum lift force | Kn | 60 |
| Maximum roll-up speed | m/min | 80 |
| Drill mast tilt side/forward/back tilt | ° | 4/5/15 |
| Chassis parameters | ||
| Maximum walking speed | Km/h | 2.5 |
| Maximum climb | % | 40 |
| Track plate width | mm | 700 |
| The maximum total width of the track | mm | 2960-4200 |
| System parameters | ||
| Work pressure | MPa | 35 |
| The quality of the whole machine | t | 53 |
| Dimensions | ||
| The working state | mm | 7862 x 4200 x 19028 |
| The shipping status | mm | 14053 x 2960 x 3295 |
