| Item | Unit | Parameter |
|---|---|---|
| Trench width | mm | 800-1500 |
| Max. Wall depth | m | 85 |
| Trench length | mm | 2800 |
| Trench accuracy | % | 12.6 |
| Max. torque | kN﹒m | 2×80 |
| Rotary | r/min | 0-25 |
| Max. pull-down piston pull | kN | 600 |
| Max. pull/push speed | m/min | 60 |
| Rope diameter | mm | 32 |
| Slag discharge way | - | pump lift discharge |
| Type of base machine | - | Special Machine |
| System pressure | Mpa | 32 |
| Work radius | mm | 5300-5900 |
| Engine | ||
| Model | - | Cummins-QSK19 |
| Rated Power | kW/rpm | 567/2100 |
| Undercarriage | ||
| Outside width of track | mm | 4050-5500 |
| Track shoe width | mm | 1000 |
| Max. traveling speed | km/h | 1 |
| Max. grade ability | % | 30 |
| Min. clearance | mm | 509 |
| Dimension | ||
| Working condition | mm | 11600×5500×18700 |
| Transportation condition | mm | 14890×3480×3350 |
| Total weight | t | 165 |
