| Items | Unit | Parameter | |
|---|---|---|---|
| Max. rated lifting capacity | Boom working condition | t | 100 |
| Boom single top working condition | t | 12 | |
| Fixed jib working condition | t | 12 | |
| Max. load moment | Boom working condition | t.m | 425 |
| Fixed jib working condition | t.m | 242 | |
| Boom single top working condition | t.m | 253 | |
| Dimension | Boom length | m | 13~61 |
| Boom luffing angle | o | -3~80.5 | |
| Fixed jib length | m | 7~19 | |
| Angle between boom and fixed jib | o | 10, 30 | |
| Boom single top | m | 1.1 | |
| Speed | Hoist winch max. single line speed | m/min | 130 |
| Boom luffing winch max. single line speed | m/min | 70 | |
| Max. slewing speed | rpm | 1.8 | |
| Max. travel speed | km/h | 1.0 | |
| Engine | Engine model | - | WP7G270E301 |
| Engine-rated power and speed | kW/rpm | 199/2000 | |
| Emission standard | - | EURO IIIA | |
| Total vehicle mass (with 13m basic boom and 100t hook block) | t | 82.2 | |
| Mean ground pressure | MPa | 0.079 | |
| Gradeability | - | 30% | |
| Max. weight of single unit for transport | t | 25.1 | |
| Max. dimension of single unit (turntable) for transport (L x W x H) | m | 13.04 x 3.4 x 3.04 | |
