| Items | Unit | Parameter | |
|---|---|---|---|
| Max. rated lifting capacity | Main boom | t | 80 |
| Jib | t | 5.5 | |
| Max. lifting moment | t.m | 302.5 | |
| Boom/jib length | Main boom | m | 12.2~47 (five boom sections) |
| jib | m | 10.5/17.5 (two jib sections) | |
| Max. boom and jib combination | m | 64.5 (47+17.5) | |
| Weight | Crane weight | t | 81.7 |
| Transport weight of basic machine (with crawler track, jib and 55t hook) | t | 55.7 | |
| Ground pressure | Mpa | 0.086 | |
| Dimension | Max. dimension of single unit in transport state (with crawler tracks) | m | 14.462 x 3.49 x 3.42 |
| Outline dimension of the crane | m | 14.462 x 5.15 x 3.424 | |
| Min. slewing radius | m | 4.538 | |
| Wire rope | Rope diameter/single line pull | mm/t | ɸ20/7.3 |
| Lifting speed | Main winch | m/min | 140 |
| Aux. winch | m/min | 90 | |
| Slewing speed | r/min | 1.8 | |
| Travel speed | km/h | 1.8 | |
| Gradeability | % | 40 | |
| Power system | Engine brand | / | Weichai |
| Power/rated speed | kW/rpm | 199/2000 | |
| Fuel tank capacity | L | 500 | |
| Emission standard | / | EU Stage III | |
